Venti Vacuum Stutzmachine

Specially designed for conveyor belt systems or for individual installation. Popular with all young plant companies.

V003 with large Ton

Machine versions V003 with cuttings utilization
(the cuttings are collected in the container bag)
- high performance 3000 plants / hour
- Pruning of potted plants and young plants in trays in one machine
- quick easy adjustment speed control knife, conveyor belt vacuum and fan
- consistent trimming quality
- cost-saving, quality-conscious pruning technology
- Shoots are pushed upwards towards the center of the pot with air before pruning
- different cutting systems can be used (fine cutting blades for young plants or blade bars for hard shoots)
- existing commercially available conveyor belts can be used
- all air flows can be electronically adjusted to the plants
- Cutting height adjustable with handwheel crank
- Frame mobile
Frame dimensions: 1.9 mx 1.5 mx 2.1 m high
Aluminum frame weight: 150 kg
base frame hot-dip galvanized steel
pneumatic tires 260
Standard blade lengths: 40 cm or 50 cm




V004 narrow version

Machine versions V004 with cuttings utilization
(the cuttings are collected in the container bag)
- high performance 3000 plants / hour
- Pruning of potted plants and young plants in trays in one machine
- quick easy adjustment speed control knife, conveyor belt vacuum and fan
- consistent trimming quality
- cost-saving, quality-conscious pruning technology
- Shoots are pushed upwards towards the center of the pot with air before pruning
- different cutting systems can be used (fine cutting blades for young plants or blade bars for hard shoots)
- existing commercially available conveyor belts can be used
- all air flows can be electronically adjusted to the plants
- Cutting height adjustable with handwheel crank
- Frame mobile
Frame dimensions: 2.2 mx 1 mx 2.2 m high
Aluminum frame weight: 150 kg
base frame hot-dip galvanized steel
Wheelbase for CC Container Dimensions
Standard blade lengths: 40 cm


vENTI VACUUM

  • Plants are sucked in with vacuum

void of wind

  • Plant parts are collected in containers
